拉杆气缸ISO 6431,167-53系列
| 微信公众号： | 上海抚御机电设备有限公司 |
| 手机： | 17701700038 |
| 座机： | 021-6271-0825 |
| FAX： | 021-6271-0826 |
| 邮箱： | zymelone@163.com |
| 客服qq： |
|
产品描述：标准 ISO 6431
工作压力范围 1,5 bar / 10 bar
环境温度范围 -20°C / +120°C
介质温度范围 -20°C / +120°C
介质 压缩空气
颗粒大小 max. 50 µm
压缩空气中的含油量 0 mg/m³ - 5 mg/m³
确定活塞推力的压力 6 bar
气缸管子 铝材, 阳极氧化处理
活塞杆 不锈钢, 镀铬
前端盖板 铝材
后盖 铝材
密封 氟-树胶
| Ø | AM | Ø B h12 | BG | C | CC | EE | KK | Ø MM | NV | P | PJ | RT |
| 25 | 22 | 23 | 12 | 8 | 20,0 | G 1/8 | M10x1,25 | 12 | 10 | – | 58 | M5 |
| 32 | 22 | 25 | 12 | 10 | 27,5 | G 1/8 | M10x1,25 | 12 | 10 | 4 | 65 | M5 |
| 40 | 24 | 35 | 15 | 13 | 30,0 | G 1/4 | M12x1,25 | 16 | 13 | 4 | 69 | M6 |
| 50 | 32 | 40 | 15 | 15 | 30,0 | G 1/4 | M16x1,5 | 20 | 17 | 4 | 72 | M6 |
| 63 | 32 | 40 | 19 | 14 | 34,0 | G 3/8 | M16x1,5 | 20 | 17 | 6 | 79 | M8 |
| 80 | 40 | 48 | 19 | 16 | 36,0 | G 3/8 | M20x1,5 | 25 | 22 | 9 | 86 | M8 |
| 100 | 40 | 55 | 23 | 16 | 40,0 | G 1/2 | M20x1,5 | 25 | 22 | 12 | 100 | M10 |
| ...Ø | TG | TS 1) | V | VD | WH | ZB | ZD |
| ...25 | 27 | +2/–1 | – | 16 | 24 | 98 ±1,2 | 74 |
| ...32 | 32 | +2/–0 | 5 | 16 | 26 | 120 ±1,2 | 94 |
| ...40 | 40 | +2/–0 | 5 | 20 | 33 | 132 ±1,2 | 99 |
| ...50 | 46 | +2/–0 | 6 | 23 | 38 | 142 ±1,2 | 104 |
| ...63 | 59 | +2,5/–0 | 6 | 27 | 41 | 154 ±1,4 | 113 |
| ...80 | 73 | +2,5/–0 | 8 | 32 | 48 | 172 ±1,4 | 124 |
| ...100 | 90 | +2,5/–0 | 8 | 37 | 53 | 187 ±1,4 | 134 |
R900927832安沃驰阀4WEH
16 J7X/6EG24N9ETK4/B08
R901108814安沃驰阀4WEH16L7X/6HG24N9ETK4/B10
R901054483安沃驰阀4WRA10EA00-2X/G24K4/V-828
R901085669安沃驰阀4WRA10EA00-2X/G24K4/V-872
R901085689安沃驰阀4WRA10EA00-2X/G24K4/V-873
R900954083安沃驰阀4WRAE10E60-2X/G24K31/A1V
R900965674安沃驰阀4WRAE10E60-2X/G24K31/F1V
R900732536安沃驰阀4WRAE10W1-60-2X/G24K31/F1V
R900949757安沃驰阀4WRAE10W1-60-2X/G24N9K31/F1V
R900954088安沃驰阀4WRAE10W60-2X/G24K31/A1V
R900710530安沃驰阀4WRAE10W60-2X/G24K31/F1V
R900974817安沃驰阀4WRAE6W1-30-2X/G24K31/F1V
R900900987安沃驰阀4WRAE6W30-2X/G24N9K31/A1V
0811404832安沃驰阀4WRBA10E64-2X/G24N9Z4/M
0811404114安沃驰阀4WRBA6E30-2X/G24N9Z4/M
0811404116安沃驰阀4WRBA6W30-2X/G24N9Z4/M
R900944121安沃驰阀4WRE6W16-2X/G24K4/V
R900962405安沃驰阀4WREE
10 W1-25-2X/G24K31/F1V
R900948360安沃驰阀4WREE
10 W75-2X/G24K31/F1V
R900927232安沃驰阀4WREE10E1-75-2X/G24K31/A1V
R900927231安沃驰阀4WREE10E50-2X/G24K31/A1V
R900927230安沃驰阀4WREE10E75-2X/G24K31/A1V
R900927356安沃驰阀4WREE10E75-2X/G24K31/F1V
R901028415安沃驰阀4WREE10R3-75-2X/G24K31/A1V
R900928553安沃驰阀4WREE6E1-32-2X/G24K31/A1V
R900920567安沃驰阀4WREE6E16-2X/G24K31/A1V
R900941623安沃驰阀4WREE6E16-2X/G24K31/F1V
R900907114安沃驰阀4WREE6E32-2X/G24K31/A1V
R900962181安沃驰阀4WREE6E32-2X/G24K31/A1V-655
R900926747安沃驰阀4WREE6V32-2X/G24K31/F1V
R900929827安沃驰阀4WREE6W1-08-2X/G24K31/A1V
R900939627安沃驰阀4WREE6W1-16-2X/G24K31/A1V
R900913359安沃驰阀4WREE6W1-32-2X/G24K31/A1V
R900925657安沃驰阀4WREE6W16-2X/G24K31/A1V
R900911004安沃驰阀4WREE6W32-2X/G24K31/A1V
R901304704安沃驰阀4WRKE32E1-600L-3X/6EG24ETK31/F1D3M
0811404180安沃驰阀4WRL
10 E80S-3X/G24Z4/M
0811404251安沃驰阀4WRLE
16 V200M-3X/G24K0/A1M
0811403001安沃驰阀4WRP10EA63S-1X/G24Z4/M
0811404778安沃驰阀4WRPE
10 W50SJ-2X/G24K0/F1M
0811404766安沃驰阀4WRPE10CB80L-2X/G24K0/F1M
0811404803安沃驰阀4WRPEH
10 C4 B100L-2X/G24K0/A1M
0811404802安沃驰阀4WRPEH
10 C4 B50L-2X/G24K0/A1M
0811404601安沃驰阀4WRPEH
6 C3 B12L-2X/G24K0/A1M
0811404632安沃驰阀4WRPEH
6 C3 B12L-2X/G24K0/F1M
0811404602安沃驰阀4WRPEH
6 C3 B24L-2X/G24K0/A1M
0811404633安沃驰阀4WRPEH
6 C3 B24L-2X/G24K0/F1M
0811404634安沃驰阀4WRPEH
6 C3 B40L-2X/G24K0/F1M
0811404611安沃驰阀4WRPEH
6 C4 B12L-2X/G24K0/A1M
0811404612安沃驰阀4WRPEH
6 C4 B24L-2X/G24K0/A1M
0811404613安沃驰阀4WRPEH
6 C4 B40L-2X/G24K0/A1M
0811404801安沃驰阀4WRPEH10C3B100L-2X/G24K0/A1M
0811404603安沃驰阀4WRPEH6C3B40L-2X/G24K0/A1M
0811404035安沃驰阀4WRPH
6 C3 B24L-2X/G24Z4/M
0811404170安沃驰阀4WRPH
6 C3 B40L-2X/G24K0/M-750
0811404902安沃驰阀4WRPH10C3B100L-2X/G24K0/M-750
0811404059安沃驰阀4WRPH10C3B100L-2X/G24Z4/M
0811404063安沃驰阀4WRPH10C3B100P-2X/G24Z4/M
0811404058安沃驰阀4WRPH10C3B50L-2X/G24Z4/M
0811404062安沃驰阀4WRPH10C3B50P-2X/G24Z4/M
0811404061安沃驰阀4WRPH10C4B100L-2X/G24Z4/M
0811404060安沃驰阀4WRPH10C4B50L-2X/G24Z4/M
0811404079安沃驰阀4WRPH10C5B100P-2X/G24Z4/M
0811404034安沃驰阀4WRPH6C3B12L-2X/G24Z4/M
0811404035安沃驰阀4WRPH6C3B24L-2X/G24Z4/M
0811404043安沃驰阀4WRPH6C3B25P-2X/G24Z4/M
0811404036安沃驰阀4WRPH6C3B40L-2X/G24Z4/M
0811404044安沃驰阀4WRPH6C3B40P-2X/G24Z4/M
0811404037安沃驰阀4WRPH6C4B12L-2X/G24Z4/M
0811404039安沃驰阀4WRPH6C4B40L-2X/G24Z4/M
0811404046安沃驰阀4WRPH6C4B40P-2X/G24Z4/M
0811404291安沃驰阀4WRVE16V200M-2X/G24K0/B5M
R900728839安沃驰阀4WRZ
16 EA150-7X/6EG24N9ETK4/M
R900969686安沃驰阀4WRZ10E85-7X/6EG24N9K4/M
R900970812安沃驰阀4WRZ16E100-7X/6EG24N9ETK4/M
R900975491安沃驰阀4WRZE
16 E150-7X/6EG24N9ETK31/A1D3M
4WRZE10W8-85-7X/6EG24N9ETK31/F1D3M
4WRZE10W8-85-7X/6EG24N9TK31/F1D3M
R910990406安沃驰阀A A10VSO 10 DR
/52R-PPA14N00
R910908725安沃驰阀A A10VSO 45 DFR1/31R-PPA12N00
R902452431安沃驰阀A A10VSO 71 DRS /32R-VPB22U99 -S2184
R910907403安沃驰阀A
A10VSO 45 DR /31R-PPA12N00
R910945133安沃驰阀A
A10VSO 71 DR /31R-PPA12N00
R902452707安沃驰阀A
A10VSO45DFR1/32R-VPB12N00-S2655
R910944440安沃驰阀A
A10VSO71DFR1/31R-PPA12N00
R910920969安沃驰阀AA10VSO100DFR/31R-VPA12N00
R910912007安沃驰阀AA10VSO100DR/31R-PPA12N00
R910922983安沃驰阀AA10VSO140DR/31R-PPB12N00
R902436353安沃驰阀A10VSO100DRS/32R-VPB12N00
S1439
R910945178安沃驰阀A10VSO18DFR1/31R-PPA12NOO
R910910590安沃驰阀A10VSO28DFR1/31R-PPA12N00
R902198402安沃驰阀A2FO23/61R-VBB05
R900501857安沃驰阀DA30-2-5X/200-17
R900598998安沃驰阀DB
10-1-5X/315
R900587772安沃驰阀DB10-2-5X/200
R900590334安沃驰阀DB10-2-5X/315
